Vibratory Micro Mill

PULVERISETTE 0

订货号
00.6020.00
产品详情

Technical Data

Working principle impact force
Optimal for material type medium-hard, brittle, temperature-sensitive, moist
Grinding tools mortar and grinding ball
Materials of the grinding tools Agate, sintered corundum, zirconium oxide, stainless steel, hardened steel, hardmetal tungsten carbide
Grinding ball diameter 50 – 70 mm
Max. feed size (depends on material) 5 mm
Min. sample quantity 1 ml
Max. sample quantity 10 ml
Final fineness (depends on material) 10 µm
Grinding time (depends on material) 10 min
Grinding process dry / wet
Cryogenic grinding yes
Grinding bowl oscillations per minute 3,000 – 3,600 at 1-3 mm amplitude
Electrical details 100-240 V/1~, 50-60 Hz, 50 Watt
Emission sound pressure level at the workplace according to DIN EN ISO 3746 (depending on the material to be ground and mortar/grinding balls used) approx. LpAd = 68 dB, with sound absorption hood approx.LpAd = 53 dB
Weight 23 kg
Dimensions (W x D x H) bench top instrument 37 x 40 x 20 cm
订货号
00.6020.00
Applications Laboratory
